CVE ID : CVE-2023-53143
Published : May 2, 2025, 4:15 p.m. | 34 minutes ago
Description : In the Linux kernel, the following vulnerability has been resolved:
ext4: fix another off-by-one fsmap error on 1k block filesystems
Apparently syzbot figured out that issuing this FSMAP call:
struct fsmap_head cmd = {
.fmh_count = …;
.fmh_keys = {
{ .fmr_device = /* ext4 dev */, .fmr_physical = 0, },
{ .fmr_device = /* ext4 dev */, .fmr_physical = 0, },
},
…
};
ret = ioctl(fd, FS_IOC_GETFSMAP, &cmd);
Produces this crash if the underlying filesystem is a 1k-block ext4
filesystem:
kernel BUG at fs/ext4/ext4.h:3331!
invalid opcode: 0000 [#1] PREEMPT SMP
CPU: 3 PID: 3227965 Comm: xfs_io Tainted: G W O 6.2.0-rc8-achx
Hardware name: QEMU Standard PC (Q35 + ICH9, 2009), BIOS 1.15.0-1 04/01/2014
RIP: 0010:ext4_mb_load_buddy_gfp+0x47c/0x570 [ext4]
RSP: 0018:ffffc90007c03998 EFLAGS: 00010246
RAX: ffff888004978000 RBX: ffffc90007c03a20 RCX: ffff888041618000
RDX: 0000000000000000 RSI: 00000000000005a4 RDI: ffffffffa0c99b11
RBP: ffff888012330000 R08: ffffffffa0c2b7d0 R09: 0000000000000400
R10: ffffc90007c03950 R11: 0000000000000000 R12: 0000000000000001
R13: 00000000ffffffff R14: 0000000000000c40 R15: ffff88802678c398
FS: 00007fdf2020c880(0000) GS:ffff88807e100000(0000) knlGS:0000000000000000
CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033
CR2: 00007ffd318a5fe8 CR3: 000000007f80f001 CR4: 00000000001706e0
Call Trace:
ext4_mballoc_query_range+0x4b/0x210 [ext4 dfa189daddffe8fecd3cdfd00564e0f265a8ab80]
ext4_getfsmap_datadev+0x713/0x890 [ext4 dfa189daddffe8fecd3cdfd00564e0f265a8ab80]
ext4_getfsmap+0x2b7/0x330 [ext4 dfa189daddffe8fecd3cdfd00564e0f265a8ab80]
ext4_ioc_getfsmap+0x153/0x2b0 [ext4 dfa189daddffe8fecd3cdfd00564e0f265a8ab80]
__ext4_ioctl+0x2a7/0x17e0 [ext4 dfa189daddffe8fecd3cdfd00564e0f265a8ab80]
__x64_sys_ioctl+0x82/0xa0
do_syscall_64+0x2b/0x80
entry_SYSCALL_64_after_hwframe+0x46/0xb0
RIP: 0033:0x7fdf20558aff
RSP: 002b:00007ffd318a9e30 EFLAGS: 00000246 ORIG_RAX: 0000000000000010
RAX: ffffffffffffffda RBX: 00000000000200c0 RCX: 00007fdf20558aff
RDX: 00007fdf1feb2010 RSI: 00000000c0c0583b RDI: 0000000000000003
RBP: 00005625c0634be0 R08: 00005625c0634c40 R09: 0000000000000001
R10: 0000000000000000 R11: 0000000000000246 R12: 00007fdf1feb2010
R13: 00005625be70d994 R14: 0000000000000800 R15: 0000000000000000
For GETFSMAP calls, the caller selects a physical block device by
writing its block number into fsmap_head.fmh_keys[01].fmr_device.
To query mappings for a subrange of the device, the starting byte of the
range is written to fsmap_head.fmh_keys[0].fmr_physical and the last
byte of the range goes in fsmap_head.fmh_keys[1].fmr_physical.
IOWs, to query what mappings overlap with bytes 3-14 of /dev/sda, you’d
set the inputs as follows:
fmh_keys[0] = { .fmr_device = major(8, 0), .fmr_physical = 3},
fmh_keys[1] = { .fmr_device = major(8, 0), .fmr_physical = 14},
Which would return you whatever is mapped in the 12 bytes starting at
physical offset 3.
The crash is due to insufficient range validation of keys[1] in
ext4_getfsmap_datadev. On 1k-block filesystems, block 0 is not part of
the filesystem, which means that s_first_data_block is nonzero.
ext4_get_group_no_and_offset subtracts this quantity from the blocknr
argument before cracking it into a group number and a block number
within a group. IOWs, block group 0 spans blocks 1-8192 (1-based)
instead of 0-8191 (0-based) like what happens with larger blocksizes.
The net result of this encoding is that blocknr s_first_data_block);
The division then operates on -1:
offset = do_div(blocknr, EXT4_BLOCKS_PER_GROUP(sb)) >>
EXT4_SB(sb)->s_cluster_bits;
Leaving an impossibly large group number (2^32-1) in blocknr.
ext4_getfsmap_check_keys checked that keys[0
—truncated—
