Migrating an Android App from MVP to Jetpack Compose: A Step-by-Step Guide

Jetpack Compose is Android’s modern toolkit for building native UI. It simplifies and accelerates UI development by using a declarative approach, which is a significant shift from the traditional imperative XML-based layouts. If you have an existing Android app written in Kotlin using the MVP (Model-View-Presenter) pattern with XML layouts, fragments, and activities, migrating to Jetpack Compose can bring numerous benefits, including improved developer productivity, reduced boilerplate code, and a more modern UI architecture.

In this article, we’ll walk through the steps to migrate an Android app from MVP with XML layouts to Jetpack Compose. We’ll use a basic News App to explain in detail how to migrate all layers of the app. The app has two screens:

A News List Fragment to display a list of news items.
A News Detail Fragment to show the details of a selected news item.

We’ll start by showing the original MVP implementation, including the Presenters, and then migrate the app to Jetpack Compose step by step. We’ll also add error handling, loading states, and use Kotlin Flow instead of LiveData for a more modern and reactive approach.

1. Understand the Key Differences

Before diving into the migration, it’s essential to understand the key differences between the two approaches:

Imperative vs. Declarative UI: XML layouts are imperative, meaning you define the UI structure and then manipulate it programmatically. Jetpack Compose is declarative, meaning you describe what the UI should look like for any given state, and Compose handles the rendering.
MVP vs. Compose Architecture: MVP separates the UI logic into Presenters and Views. Jetpack Compose encourages a more reactive and state-driven architecture, often using ViewModel and State Hoisting.
Fragments and Activities: In traditional Android development, Fragments and Activities are used to manage UI components. In Jetpack Compose, you can replace most Fragments and Activities with composable functions.

2. Plan the Migration

Migrating an entire app to Jetpack Compose can be a significant undertaking. Here’s a suggested approach:

Start Small: Begin by migrating a single screen or component to Jetpack Compose. This will help you understand the process and identify potential challenges.
Incremental Migration: Jetpack Compose is designed to work alongside traditional Views, so you can migrate your app incrementally. Use ComposeView in XML layouts or AndroidView in Compose to bridge the gap.
Refactor MVP to MVVM: Jetpack Compose works well with the MVVM (Model-View-ViewModel) pattern. Consider refactoring your Presenters into ViewModels.
Replace Fragments with Composable Functions: Fragments can be replaced with composable functions, simplifying navigation and UI management.
Add Error Handling and Loading States: Ensure your app handles errors gracefully and displays loading states during data fetching.
Use Kotlin Flow: Replace LiveData with Kotlin Flow for a more modern and reactive approach.

3. Set Up Jetpack Compose

Before starting the migration, ensure your project is set up for Jetpack Compose:

Update Gradle Dependencies:
Add the necessary Compose dependencies to your build.gradle file:

android {
    ...
    buildFeatures {
        compose true
    }
    composeOptions {
        kotlinCompilerExtensionVersion '1.5.3'
    }
}

dependencies {
    implementation 'androidx.activity:activity-compose:1.8.0'
    implementation 'androidx.compose.ui:ui:1.5.4'
    implementation 'androidx.compose.material:material:1.5.4'
    implementation 'androidx.compose.ui:ui-tooling-preview:1.5.4'
    implementation 'androidx.lifecycle:lifecycle-viewmodel-compose:2.6.2'
    implementation 'androidx.navigation:navigation-compose:2.7.4' // For navigation
    implementation 'androidx.lifecycle:lifecycle-runtime-ktx:2.6.2' // For Flow
    implementation 'org.jetbrains.kotlinx:kotlinx-coroutines-core:1.7.3' // For Flow
}

Enable Compose in Your Project:
Ensure your project is using the correct Kotlin and Android Gradle plugin versions.

4. Original MVP Implementation

a. News List Fragment and Presenter

The NewsListFragment displays a list of news items. The NewsListPresenter fetches the data and updates the view.

NewsListFragment.kt

class NewsListFragment : Fragment(), NewsListView {

    private lateinit var presenter: NewsListPresenter
    private lateinit var adapter: NewsListAdapter

    override fun onCreateView(
        inflater: LayoutInflater, container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        val view = inflater.inflate(R.layout.fragment_news_list, container, false)
        val recyclerView = view.findViewById<RecyclerView>(R.id.recyclerView)
        adapter = NewsListAdapter { newsItem -> presenter.onNewsItemClicked(newsItem) }
        recyclerView.adapter = adapter
        recyclerView.layoutManager = LinearLayoutManager(context)
        presenter = NewsListPresenter(this)
        presenter.loadNews()
        return view
    }

    override fun showNews(news: List<NewsItem>) {
        adapter.submitList(news)
    }

    override fun showLoading() {
        // Show loading indicator
    }

    override fun showError(error: String) {
        // Show error message
    }
}

NewsListPresenter.kt

class NewsListPresenter(private val view: NewsListView) {

    fun loadNews() {
        view.showLoading()
        // Simulate fetching news from a data source (e.g., API or local database)
        try {
            val newsList = listOf(
                NewsItem(id = 1, title = "News 1", summary = "Summary 1"),
                NewsItem(id = 2, title = "News 2", summary = "Summary 2")
            )
            view.showNews(newsList)
        } catch (e: Exception) {
            view.showError(e.message ?: "An error occurred")
        }
    }

    fun onNewsItemClicked(newsItem: NewsItem) {
        // Navigate to the news detail screen
        val intent = Intent(context, NewsDetailActivity::class.java).apply {
            putExtra("newsId", newsItem.id)
        }
        startActivity(intent)
    }
}

NewsListView.kt

interface NewsListView {
    fun showNews(news: List<NewsItem>)
    fun showLoading()
    fun showError(error: String)
}

b. News Detail Fragment and Presenter

The NewsDetailFragment displays the details of a selected news item. The NewsDetailPresenter fetches the details and updates the view.

NewsDetailFragment.kt

class NewsDetailFragment : Fragment(), NewsDetailView {

    private lateinit var presenter: NewsDetailPresenter

    override fun onCreateView(
        inflater: LayoutInflater, container: ViewGroup?,
        savedInstanceState: Bundle?
    ): View? {
        val view = inflater.inflate(R.layout.fragment_news_detail, container, false)
        presenter = NewsDetailPresenter(this)
        val newsId = arguments?.getInt("newsId") ?: 0
        presenter.loadNewsDetail(newsId)
        return view
    }

    override fun showNewsDetail(newsItem: NewsItem) {
        view?.findViewById<TextView>(R.id.title)?.text = newsItem.title
        view?.findViewById<TextView>(R.id.summary)?.text = newsItem.summary
    }

    override fun showLoading() {
        // Show loading indicator
    }

    override fun showError(error: String) {
        // Show error message
    }
}

NewsDetailPresenter.kt

class NewsDetailPresenter(private val view: NewsDetailView) {

    fun loadNewsDetail(newsId: Int) {
        view.showLoading()
        // Simulate fetching news detail from a data source (e.g., API or local database)
        try {
            val newsItem = NewsItem(id = newsId, title = "News $newsId", summary = "Summary $newsId")
            view.showNewsDetail(newsItem)
        } catch (e: Exception) {
            view.showError(e.message ?: "An error occurred")
        }
    }
}

NewsDetailView.kt

interface NewsDetailView {
    fun showNewsDetail(newsItem: NewsItem)
    fun showLoading()
    fun showError(error: String)
}

5. Migrate to Jetpack Compose

a. Migrate the News List Fragment

Replace the NewsListFragment with a composable function. The NewsListPresenter will be refactored into a NewsListViewModel.

NewsListScreen.kt

@Composable
fun NewsListScreen(viewModel: NewsListViewModel, onItemClick: (NewsItem) -> Unit) {
    val newsState by viewModel.newsState.collectAsState()

    when (newsState) {
        is NewsState.Loading -> {
            // Show loading indicator
            CircularProgressIndicator()
        }
        is NewsState.Success -> {
            val news = (newsState as NewsState.Success).news
            LazyColumn {
                items(news) { newsItem ->
                    NewsListItem(newsItem = newsItem, onClick = { onItemClick(newsItem) })
                }
            }
        }
        is NewsState.Error -> {
            // Show error message
            val error = (newsState as NewsState.Error).error
            Text(text = error, color = Color.Red)
        }
    }
}

@Composable
fun NewsListItem(newsItem: NewsItem, onClick: () -> Unit) {
    Card(
        modifier = Modifier
            .fillMaxWidth()
            .padding(8.dp)
            .clickable { onClick() }
    ) {
        Column(modifier = Modifier.padding(16.dp)) {
            Text(text = newsItem.title, style = MaterialTheme.typography.h6)
            Text(text = newsItem.summary, style = MaterialTheme.typography.body1)
        }
    }
}

NewsListViewModel.kt

class NewsListViewModel : ViewModel() {

    private val _newsState = MutableStateFlow<NewsState>(NewsState.Loading)
    val newsState: StateFlow<NewsState> get() = _newsState

    init {
        loadNews()
    }

    private fun loadNews() {
        viewModelScope.launch {
            _newsState.value = NewsState.Loading
            try {
                // Simulate fetching news from a data source (e.g., API or local database)
                val newsList = listOf(
                    NewsItem(id = 1, title = "News 1", summary = "Summary 1"),
                    NewsItem(id = 2, title = "News 2", summary = "Summary 2")
                )
                _newsState.value = NewsState.Success(newsList)
            } catch (e: Exception) {
                _newsState.value = NewsState.Error(e.message ?: "An error occurred")
            }
        }
    }
}

sealed class NewsState {
    object Loading : NewsState()
    data class Success(val news: List<NewsItem>) : NewsState()
    data class Error(val error: String) : NewsState()
}

b. Migrate the News Detail Fragment

Replace the NewsDetailFragment with a composable function. The NewsDetailPresenter will be refactored into a NewsDetailViewModel.

NewsDetailScreen.kt

@Composable
fun NewsDetailScreen(viewModel: NewsDetailViewModel) {
    val newsState by viewModel.newsState.collectAsState()

    when (newsState) {
        is NewsState.Loading -> {
            // Show loading indicator
            CircularProgressIndicator()
        }
        is NewsState.Success -> {
            val newsItem = (newsState as NewsState.Success).news
            Column(modifier = Modifier.padding(16.dp)) {
                Text(text = newsItem.title, style = MaterialTheme.typography.h4)
                Text(text = newsItem.summary, style = MaterialTheme.typography.body1)
            }
        }
        is NewsState.Error -> {
            // Show error message
            val error = (newsState as NewsState.Error).error
            Text(text = error, color = Color.Red)
        }
    }
}

NewsDetailViewModel.kt

class NewsDetailViewModel : ViewModel() {

    private val _newsState = MutableStateFlow<NewsState>(NewsState.Loading)
    val newsState: StateFlow<NewsState> get() = _newsState

    fun loadNewsDetail(newsId: Int) {
        viewModelScope.launch {
            _newsState.value = NewsState.Loading
            try {
                // Simulate fetching news detail from a data source (e.g., API or local database)
                val newsItem = NewsItem(id = newsId, title = "News $newsId", summary = "Summary $newsId")
                _newsState.value = NewsState.Success(newsItem)
            } catch (e: Exception) {
                _newsState.value = NewsState.Error(e.message ?: "An error occurred")
            }
        }
    }
}

sealed class NewsState {
    object Loading : NewsState()
    data class Success(val news: NewsItem) : NewsState()
    data class Error(val error: String) : NewsState()
}

6. Set Up Navigation

Replace Fragment-based navigation with Compose navigation:

class MainActivity : ComponentActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContent {
            NewsApp()
        }
    }
}

@Composable
fun NewsApp() {
    val navController = rememberNavController()
    NavHost(navController = navController, startDestination = "newsList") {
        composable("newsList") {
            val viewModel: NewsListViewModel = viewModel()
            NewsListScreen(viewModel = viewModel) { newsItem ->
                navController.navigate("newsDetail/${newsItem.id}")
            }
        }
        composable("newsDetail/{newsId}") { backStackEntry ->
            val viewModel: NewsDetailViewModel = viewModel()
            val newsId = backStackEntry.arguments?.getString("newsId")?.toIntOrNull() ?: 0
            viewModel.loadNewsDetail(newsId)
            NewsDetailScreen(viewModel = viewModel)
        }
    }
}

7. Test and Iterate

After migrating the screens, thoroughly test the app to ensure it behaves as expected. Use Compose’s preview functionality to visualize your UI:

@Preview(showBackground = true)
@Composable
fun PreviewNewsListScreen() {
    NewsListScreen(viewModel = NewsListViewModel(), onItemClick = {})
}

@Preview(showBackground = true)
@Composable
fun PreviewNewsDetailScreen() {
    NewsDetailScreen(viewModel = NewsDetailViewModel())
}

8. Gradually Migrate the Entire App

Once you’re comfortable with the migration process, continue migrating the rest of your app incrementally. Use ComposeView and AndroidView to integrate Compose with existing XML
